Lcd video wall
SHENZHEN LG 46inch 2×2 3×3 4K Daisy Chain LCD splicing screen video wall controller display
46inch 1.7mm bezel size 1920×1080 LCD digital signage video wall controller display,LTI460HN14 1.7mm patchwork display features
1. A-grade LCD panels and components meet long-term uninterrupted use, unique Samsung/LG original DID LCD splicing display, support 365 days 7X24 hours uninterrupted monitoring display.
2. Automatic backlight brightness adjustment technology:LCD screen automatically adjust the backlight brightness according to the light and dark conditions of the environment to present the best picture display effect. At the same time, it conforms to ergonomic principles and protects the eyes to be comfortable to watch in different environments.
3. Intelligent screen saver: After the image is displayed for 30 minutes (time is selectable in the menu), it will automatically move left and right for 2 seconds and then return to the initial state display to prevent the monitor from remaining burned on the LCD screen due to long static images. Shadow.
4. Compatible with HD and SD multi-format signal input (HDMI, DVI, VGA, BNC )
-
4K 46inch 1.7mm bezel size 1920×1080 LCD digital signage video wall controller display
4K Daisy Chain 2*2 55inch Samsung Touch Screen Video Wall, Floor standing Big TV Wall in 1.7mm bezel and 500cd/m2 brightnessYameishi has various size video wall in narrow bezel and high brightness, installation can be 2*2, 2*3, 4*3, 3*3 and so on, can be installed on the wall or have a floor standing cabinet.10-point IR touch screen frame on option so the video wall can be multi-touch and interactive.
1). The physical resolution is 1920 * 1080, which is compatible with the resolution below, and automatically adjusted to the best state.2). AC100V-240V alternating current to directly supply power, which makes the product application area wider.3). Automatically identify PAL / NTSC video format.4). Support local infrared remote control and RS232 control operation.5). With 3D comb filter, dynamic noise reduction technology, and frame compensation function, highly restored real picture using Samsung or LG‘s unique DID screen, which can be placed horizontally or vertically, and has "automatic constant temperature" adjustment. Features.6). It can automatically detect the internal temperature, so that the fan can reduce the internal temperature, long life (60,000 hours), stable operation, no burns, damage, low maintenance costs, unique modular design, can be used as a splicing wall Use, can also be used alone.Place of Origin:
CHINAModel Number:
YMS-470ACertification:CE/ROHS/FCC/SGS
Splicing screen specification:Minimum Order Quantity:
1PCSPackaging Details:
Packed in carton firstly,and then reinforced with wooden case for outer packing
Delivery Time:
10 working days after received your payment
Supply Ability:3,000pcs per month
LG Panel Application Details
Basic Info
Panel BrandLG/SAMSUNGPanel ModelLTI460HN14Panel Typea-Si TFT-LCD , LCMStorage Temp.-20 ~ 60 °CPixel FeaturesPixel Format1920(RGB)×1080, FHDDot Pitch0.17675×0.53025 mmConfigurationRGB Vertical StripePixel Pitch0.53025×0.53025 mmMechanical SizeActive Viewing1018.08×572.67 mmOutline Dim.1020.02×574.61 mmBezel Opening1018.28(W)×572.87(H) mm
Outline Depth38.7/68.1 (Typ./Max.) mm
Outline FeaturesForm FactorFlat RectangleOrientationLandscape / PortraitAspect Ratio16:9 (H:V)Videowall Seam1.7 mm (Active to Active)
Other FeaturesWeight11.5/13.5Kgs (Typ./Max.)
SurfaceAntiglare (Haze 25%), Hard coating (2H)
Optical DetailsBasic InformationBrightness500 cd/m² (Typ.)Contrast Ratio4000:1 (Typ.) (Transmissive)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Optical ModeS-IPS, Normally Black, Transmissive
Viewing DirectionSymmetryResponse Time8 (Typ.)(G to G) msColor PerformanceChromaticityWx:0.280; Wy:0.290Color Numbers16.7M/1.07B (8-bit / 8-bit + Dithering)
Color Temperature9085KUniformity1.33 (Max.)(9 points)1931 Color GamltNTSC Ratio71%sRGB100% coverageAdobe RGB74% coverageDCI-P374% coverageRec.202053% coverageRemarkssRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Frame Frequency60HzReverse ScanNoPower Consumption82.1W (Typ.)Power supplyAC 110V - 240V, 50/60HZ
Storage Temperature-7 to 65 Celsius degreeNormal Working Temperature
-5 to 65 Celsius degree
Why choose us:1. >8-years professional manufacturing experience only in digital signage field.2. LCD display projects from 8" to 108‘ in various brightness can be tailor-made according to your specific requirements.3. Rich experience in OEM and ODM projects in more than 10 years.4. Less MOQ can meet your various requirements.5. Fast delivery time, sample needs 10-15days, bulk needs 15-20days, have stock of standard item.6. Flexible Payment term: support T/T, L/C, Westunion, Paypal.7. Shipments: Internation express, airfreight, oceanfreight.8. Warranty: 2-years warranty, lifetime maintenance.FAQQ: Is your company a real manufacturer?A: Yes, sure. Shenzhen Yameishi Technology Co.,Ltd is a professional manufacturer in Longgang district, Shenzhen city, welcome to visit our factoryanytime.Q:Can you provide OEM service for the all in one smart interactive whiteboard?A: Yes,well supported.We can customize it according to your requests.Q:Do you have stock?A:We keep 2000 units in Stock every single Month.Q: How is the quality of the product?A: We have a dust-free workshop, all our products have been strictly tested high quality by QC before shipping to customers.quality is the first thing for us!Q: How can I trust your product quality?A: We have more than 8 years export experience. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE/ROHS/FCC etc.Q: Does the product only use for school?A: Yes, our products are widely used in Hospital, School, office etc.Q: What‘s your after-sale service?A: 2 years warranty on parts is provided under normal use. If any defects happen during the period, please send us the details and you will get our reply within 24 hours. Solution will be offered instantly. If necessary, spare parts for free can be provided.
